NSE 7 - Secure Networking 7.6 Architect Exam Materials-Question 32 Discussion
Comment Image Comment Image Comment Image

Refer to the exhibits. The configuration of an SD-WAN rule and the corresponding rule status and routing table are shown. You want to understand the expected behavior for traffic that matches the SD-WAN rule, at the time the output was collected. Based on the exhibits, which behavior can you expect for traffic that matches the SD-WAN rule? (Choose one answer)

  • A. The traffic will be load balanced across all three overlays.
  • B. The traffic will be routed over HUB1-VPN3.
  • C. The traffic will be routed over HUB1-VPN1.
  • D. The traffic will be routed over HUB1-VPN2.
Correct Answer: D

Brave-Dump Clients Votes

D 66.67%
B 33.33%

Comments



imade 2026-08-14 01:12:39

Selected Answers: B


B. The traffic will be routed over HUB1-VPN3. HUB1-VPN3 0x3 = both SLAs passed
  • Bob 2026-08-15 12:15:02
    I think that D. B - I think that's not true. How can this be (Answer B) if there is no route to the required network through hub3?

Md Nasir Uddin 2026-08-29 15:03:17

Selected Answers: D


Yes, Bob D is right Answer

Ali 2026-08-30 00:20:39

Selected Answers: D


D is correct
