Refer to the exhibits. The first exhibit shows the SD-WAN zone HUB1 and SD-WAN member configuration from an SD-WAN template, and the second exhibit shows the output of command diagnose sys sdwan member collected on a FortiGate device. Which statement best describes what the diagnose output shows? (Choose one answer)

A. The diagnose output shows that HUB1-VPN1 and all HUBx-VPNy members are dead.
B. The diagnose output does not correspond to a device configured with the SD-WAN template shown in the exhibit.
C. The diagnose output was collected on the device branch2_fgt.
D. The diagnose output was collected on the device branch1_fgt.

Correct Answer: D

Brave-Dump Clients Votes

D 66.67%

C 16.67%

B 16.67%

Comments

user 2025-08-22 05:28:59

Selected Answers: C

@Omar It can't be B as the diagnose sys sdwan member output correspond to SD-WAN template 1

user 2025-08-22 16:59:32

Selected Answers: D

HUB1-VPN3 is not in the dig sys sdwan member output change my answer to D

Carlos Navarro 2025-08-26 17:31:09

Selected Answers: B

Mattia Bruno 2025-08-27 16:56:20

Selected Answers: D

D if there are not installations target it's for everyone but the HUB1-VPN3 doesn't have the branch 1 as installation target

Carlos Navarro 2025-08-28 18:04:28

Selected Answers: D

Yes, D pg. 118

Mohamed 2025-11-04 01:04:54

Selected Answers: D

leaving the Installation Target empty will install the configuration on ALL devices - see page 119 of SD-WAN 7.4 Architect:

"To define an installation target, you can select device groups or individual devices. Leave the Installation Target field empty to install the member on every device."

Because the only one the output does not have is HUB1-VPN3, this must be branch1_fgt - so the answer is D
