Question 34 Discussion

Refer to the exhibit. A network diagram showing the corporate network and a new remote office network is shown. You must integrate the new remote office network with the corporate enterprise network. What must you do to allow routing between the two networks? (Choose one answer)

  • A. Implement BGP to inject the new remote office network into the corporate FortiGate device.
  • B. Configure virtual links on both FortiGate devices.
  • C. Add the network 192.168.1.0/24 in the OSPF section on the corporate FortiGate device.
  • D. Implement OSPF over IPsec on both FortiGate devices.
Correct Answer: D

Brave-Dump Clients Votes

D 100%

Comments



Adam 2026-01-19 08:43:14

Selected Answers: D


from Study Guide:
Site-to-site OSPF requires route-based IPsec VPN tunnels with complete phase1 and phase2 configuration. On both FortiGate devices, the phase1 configuration must have tunnel-end IP addresses assigned on tunnel interfaces. OSPF must be defined on the VPN tunnel interfaces as part of the OSPF interface configuration.

A is wrong as it complicates the setup by adding BGP while we already use OSPF in local sites
B is wrong as we just extend Area 0 over IPsec tunnel interfaces without the need for virtual link
C is wrong as the network belongs to remote site
