Question 18 Discussion

Refer to the exhibits. Two SD-WAN event logs, the member status, the SD-WAN rule configuration, and the health-check configuration for a FortiGate device are shown. Immediately after the log messages are displayed, how will the FortiGate steer the traffic based on the information shown in the exhibits? (Choose one answer)

  • A. FortiGate skips SD-WAN rule ID 1.
  • B. FortiGate uses port2 to steer the traffic for SD-WAN rule ID 1.
  • C. FortiGate uses port1 to steer the traffic for SD-WAN rule ID 1.
  • D. FortiGate uses port1 or port2 to steer the traffic for SD-WAN rule ID 1.
Correct Answer: B

Brave-Dump Clients Votes

B 100%

Comments



Brave-Dumps Admin 2025-10-22 12:40:57

Selected Answers: B


The event log shows that Member 1 failed the SLA test under Corp_HC.

The SD-WAN rule ID 1 (Critical-DIA) works in SLA mode and has priority members 1 and 2.

Since Member 1 failed, FortiGate stops using it and automatically switches the traffic to Member 2 (port2) right after the log appears.

What do you think?

FortiXpert 2025-11-02 01:12:35

Selected Answers: B


there is log event that shows sla for member 1 is out of sla which means it is not meeting the threshold value so in that case it will select member 2 which is port2
