Implementing and Operating Cisco Security Core Technologies v1.1 (350-701 SCOR v1.1) Exam Materials-Question 283 Discussion
Comment Image Comment Image Comment Image

Refer to the exhibit. A network engineer configures a network on a Cisco switch that has interVLAN routing where PC1 belongs to VLAN10 and PC2 belongs to VLAN20. R1 is the gateway and provides internet connectivity. R1 has been configured with subinterfaces for VLAN 10 and VLAN 20. S1 and S2 have been configured with VLAN 20 and port F0/18 on S2 is assigned is configured as access port and assigned to VLAN 20. Which configuration action must be done next on S1 to allow PC1 to connect to the internet? (Choose one answer)

  • A. Create VLAN10 and assign port G0/0/1.
  • B. Create VLAN10 and assign port Fa0/6.
  • C. Create VLAN10.
  • D. Delete VLAN20 and recreate new VLANs.
Correct Answer: B

Brave-Dump Clients Votes

B 100%

Comments



Anonymous User 2026-06-29 18:13:51

Selected Answers: B


there is duplicate questions in the previous page the answer is letter B whoch is correct because you need to assigned access vlan to the interface with configuring access vlan you can't get an ip address of vlan 10 from DCHP Server pool
